1 Display the User Calibration Window.
For the display methods, refer to A-10 Displaying the User Calibration Window on page
A - 59.
2 Click the
Clear All Button under All Channel Settings.
An execution confirmation dialog box is displayed.
3 Click the Yes Button. When the writing is completed successfully, the following dialog box is
displayed. Click the OK Button.
8 Functions
8 - 37
NX-series Analog I/O Units User’s Manual for High-speed Analog Input Units (W592)
8-8 User Calibration
8
8-8-3 Setting Method
