A 100-ms timer delay (the time required for an OMRON Proximity Sensor to stabilize) is created in
the user program.
After the timer changes to TRUE, input bit X causes the output Output to change to TRUE after the
input of the sensor changes to TRUE.
TON
T#100ms
X Output
Sensor_power
4 Installation and Wiring
4 - 31
NX-series Analog I/O Units User’s Manual for High-speed Analog Input Units (W592)
4-4 Wiring External Devices
4
4-4-3 Precautions for Wiring
