Omron V430-F Series User Manual For Communication Settings

Member Name Size (Bytes)
DECODE CYCLE REPORT 16
DECODE DATA LENGTH 4
DECODE DATA STRING 184
Total Size: 248 Bytes
Member Description
• INFO BITS
Bit State Description
0 Run Mode Is 1 when Read Cycle is enabled.
1 Connection Faulted Always 0 while connected.
2 - 7 Reserved ‐
• Configuration Change Detection
This bit is set to 1 if any configuration changes are made to the code reader after connecting.
If the setting is returned to the original state, 0 is set.
• Device Status
Shows the current status of the code reader.
Bit State
0 Run Mode
1 Trigger Acknowledged
2 Exposure Done
3 Decoding
4 Data Is Ready
5 Read Cycle Pass
6 Read Cycle Fail
7 General Fault
8 New Matchcode Acknowledged
9 Matchcode Enabled
10 Image Sensor Calibrating
11 Image Sensor Calibration Complete
12 Training
13 Training Complete
14 Optimizing
15 Optimization Complete
16 AutoImage Photometry Enabled
17 AutoImage Photometry Complete
18 Output 1 Status
19 Output 2 Status
20 Output 3 Status
21 Buffer Overflow
22 - 30 Reserved
・Run Mode
Shows Read Cycle Enabled/Disabled status.
0 = Read Cycle Disabled cannot accept Trigger. However, it can receive a command.
1 = Read Cycle Enabled State in which trigger can be accepted.
・Trigger Acknowledged
Appendices
A - 9
V430-F Series Autofocus Multicode Reader User Manual for Communication Settings
A-2 EtherNet/IP Detailed Specifications
A
A-2-1 Assembly Memory Allocation
