Omron V430-F Series User Manual For Communication Settings

Member Name Data Type Bit Number Data Length Byte Offset
32 bit Decode Location Top 0 - 15 2 byte
Decode Location Left 0 - 15 2 byte
32 bit Decode Location Height 0 - 15 2 byte
Decode Location Width 0 - 15 2 byte
32 bit Code Type DINT 4 Byte 52
Aztec Code 0 1 bit
Micro QR Code 1 1 bit
Postal Code 2 1 bit
Code 39 3 1 bit
Codabar 4 1 bit
Interleaved 2 of 5 5 1 bit
UPC EAN 6 1 bit
Code 128 EAN 128 7 1 bit
Code 93 8 1 bit
PDF417 9 1 bit
Pharma Code 10 1 bit
DataMatrix 11 1 bit
QR Code 12 1 bit
BC412 13 1 bit
RSS14 14 1 bit
RSS14 LTD 15 1 bit
RSS14 EXP 16 1 bit
Micro PDF 17 1 bit
Composite 18 1 bit
Dot Code 19 1 bit
Reserved 20 - 31 12 bit
32 bit Pixels per Element REAL 0 - 31 4 byte 56
32 bit Decode Data Length DINT 0 - 31 4 byte 60
Decode Data String SINT[184] 0 - 1472 184 byte 64
1 Decode Input Assembly (Instance ID: 103)
1 Decode Input Assembly is designed to hold a 436 byte Read result string. When reading multiple
symbols, the Read strings are output delimited by Separator Characters.
1 Decode Input Assembly Member Structure
Member Name Size (Bytes)
INFO BITS 1
RESERVED 1
CONFIGURATION CHANGE DETECTION 1
RESERVED 1
DEVICE STATUS 4
FAULT CODE 4
COUNTERS 24
READ CYCLE REPORT 8
DECODE CYCLE REPORT 8
DECODE DATA LENGTH 4
Appendices
A - 15
V430-F Series Autofocus Multicode Reader User Manual for Communication Settings
A-2 EtherNet/IP Detailed Specifications
A
A-2-1 Assembly Memory Allocation
CODE TYPE 4
PIXELS PER ELEMENT 4
DECODE DATA STRING 436
Total Size: 500 Bytes
