Omron V430-F Series User Manual For Communication Settings

Member Description
• INFO BITS
MXL/SLC Input Assembly (Instance ID: 102) on page A - 8 - Same structure as
• Configuration Change Detection
MXL/SLC Input Assembly (Instance ID: 102) on page A - 8.
• Device Status
MXL/SLC Input Assembly (Instance ID: 102) on page A - 8 - Same structure as
• Error Code
MXL/SLC Input Assembly (Instance ID: 102) on page A - 8 - Same structure as
• Counters
MXL/SLC Input Assembly (Instance ID: 102) on page A - 8 - Same structure as
• Read Cycle Report
MXL/SLC Input Assembly (Instance ID: 102) on page A - 8 - Same structure as
• Decode Cycle Report
MXL/SLC Input Assembly (Instance ID: 102) on page A - 8 - Same structure as
• Decode Data Length
Stores the number of characters in the Read string.
• Decode Data String
Stores the Read string. When additional information such as Print Quality Grading Standard is set, it
is stored following the Read string.
Assembly Memory Allocation
Member Name Data Type Bit Number Data Length Byte Offset
32 bit InfoBits SINT 1 Byte 0
Bit Run Mode 0 1 bit
Bit Connection Faulted 1 1 bit
Reserved 2 1 bit
Reserved 3 - 7 5 bit
Reserved SINT 1 Byte 1
Configuration Change
Detection
SINT 1 Byte 2
Config Change Detect 0 1 bit
Reserved 1 - 7 7 bit
Reserved ‐ 1 byte 3
Appendices
A - 16
V430-F Series Autofocus Multicode Reader User Manual for Communication Settings
