Omron V430-F Series User Manual For Communication Settings

Member Name Data Type Bit Number Data Length Byte Offset
32 bit Decode Location Top 0 - 15 2 byte
Decode Location Left 0 - 15 2 byte
32 bit Decode Location Height 0 - 15 2 byte
Decode Location Width 0 - 15 2 byte
32 bit Code Type DINT 4 Byte 52
Aztec Code 1 bit
Micro QR Code 1 bit
Postal Code 1 bit
Code 39 1 bit
Codabar 1 bit
Interleaved 2 of 5 1 bit
UPC EAN 1 bit
Code 128 EAN 128 1 bit
Code 93 1 bit
PDF417 1 bit
Pharma Code 1 bit
DataMatrix 1 bit
QR Code 1 bit
BC412 1 bit
RSS14 1 bit
RSS14 LTD 1 bit
RSS14 EXP 1 bit
Micro PDF 1 bit
Composite 1 bit
Dot Code 1 bit
Reserved 12 bit
32 bit Pixels per Element REAL 0 - 31 4 byte 56
32 bit Decode Data Length DINT 0 - 31 4 byte 60
Decode Data String SINT[436] 0 - 3487 436 byte 64
4 Decode Input Assembly (Instance ID: 104)
4 Decode Input Assembly is designed to hold the Read result information of 4 symbols. The first Read
result is stored in a 160 byte field. The remaining Read results are stored in a 72 byte field. Use this
when you want to execute a multiple symbol Read for up to 4 symbols and query symbol information
such as symbol position coordinates for each symbol.
4 Decode Input Assembly Member Structure
Member Name Size (Bytes)
INFO BITS 1
RESERVED 1
CONFIGURATION CHANGE DETECTION 1
RESERVED 1
DEVICE STATUS 4
FAULT CODE 4
COUNTERS 24
READ CYCLE REPORT 8
Appendices
A - 18
V430-F Series Autofocus Multicode Reader User Manual for Communication Settings
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20 - 31
