Member Name Size (Bytes)
DECODE 1 CYCLE REPORT 16
DECODE 1 LENGTH 4
DECODE 1 DATA 160
DECODE 2 CYCLE REPORT 16
DECODE 2 LENGTH 4
DECODE 2 DATA 72
DECODE 3 CYCLE REPORT 16
DECODE 3 LENGTH 4
DECODE 3 DATA 72
DECODE 4 CYCLE REPORT 16
DECODE 4 LENGTH 4
DECODE 4 DATA 72
Total Size: 500 Bytes
Member Description
• INFO BITS
MXL/SLC Input Assembly (Instance ID: 102) on page A - 8 - Same structure as
• Configuration Change Detection
MXL/SLC Input Assembly (Instance ID: 102) on page A - 8 - Same structure as
• Device Status
MXL/SLC Input Assembly (Instance ID: 102) on page A - 8 - Same structure as
• Error Code
MXL/SLC Input Assembly (Instance ID: 102) on page A - 8 - Same structure as
• Counters
MXL/SLC Input Assembly (Instance ID: 102) on page A - 8 - Same structure as
• Read Cycle Report
MXL/SLC Input Assembly (Instance ID: 102) on page A - 8 - Same structure as
• Decode 1 Cycle Report
The information for the 1st symbol. MXL/SLC Input Assembly (Instance ID: 102) on page A - 8 -
Same structure as
• Decode 1 Length
Stores the number of characters that comprise the 1st symbol.
• Decode 1 Data
Stores the Read string of the 1st symbol. When additional information such as Print Quality Grading
Standard is set, it is stored following the Read string.
• Decode 2 Cycle Report
The information for the 2nd symbol. MXL/SLC Input Assembly (Instance ID: 102) on page A - 8 -
Same structure as
• Decode 2 Length
Stores the number of characters that comprise the 2nd symbol.
• Decode 2 Data
Stores the Read string of the 2nd symbol. When additional information such as Print Quality Grading
Standard is set, it is stored following the Read string.
• Decode 3 Cycle Report
The information for the 3rd symbol. MXL/SLC Input Assembly (Instance ID: 102) on page A - 8 -
Same structure as
• Decode 3 Length
Appendices
A - 19
V430-F Series Autofocus Multicode Reader User Manual for Communication Settings
A-2 EtherNet/IP Detailed Specifications
A
A-2-1 Assembly Memory Allocation
