Stores the number of characters that comprise the 3rd symbol.
• Decode 3 Data
Stores the Read string of the 3rd symbol. When additional information such as Print Quality Grading
Standard is set, it is stored following the Read string.
• Decode 4 Cycle Report
The information for the 4th symbol. MXL/SLC Input Assembly (Instance ID: 102) on page A - 8 -
Same structure as
• Decode 4 Length
Stores the number of characters that comprise the 4th symbol.
• Decode 4 Data
Stores the Read string of the 4th symbol. When additional information such as Print Quality Grading
Standard is set, it is stored following the Read string.
Assembly Memory Allocation
Member Name Data Type Bit Number Data Length Byte Offset
32 bit InfoBits SINT 1 Byte 0
Bit Run Mode 0 1 bit
Bit Connection Faulted 1 1 bit
Reserved 2 1 bit
Reserved 3 - 7 5 bit
Reserved SINT 1 Byte 1
Configuration Change
Detection
SINT 1 Byte 2
Config Change Detect 0 1 bit
Reserved 1 - 7 7 bit
Reserved ‐ 1 byte 3
Appendices
A - 20
V430-F Series Autofocus Multicode Reader User Manual for Communication Settings
