Omron V430-F Series - Page 135

Member Name Data Type Bit Number Data Length Byte Offset
32 bit Code Type DINT 4 Byte 324
Aztec Code 0 1 bit
Micro QR Code 1 1 bit
Postal Code 2 1 bit
Code 39 3 1 bit
Codabar 4 1 bit
Interleaved 2 of 5 5 1 bit
UPC EAN 6 1 bit
Code 128 EAN 128 7 1 bit
Code 93 8 1 bit
PDF417 9 1 bit
Pharma Code 10 1 bit
DataMatrix 11 1 bit
QR Code 12 1 bit
BC412 13 1 bit
RSS14 14 1 bit
RSS14 LTD 15 1 bit
RSS14 EXP 16 1 bit
Micro PDF 17 1 bit
Composite 18 1 bit
Dot Code 19 1 bit
Reserved 20 - 31 12 bit
32 bit Pixels per Element REAL 0 - 31 4 byte 328
32 bit Decode 3 Length DINT 0 - 31 4 byte 332
Decode 3 Data SINT[72] 0 - 575 72 byte 336
Decode 4 Cycle Report INT[4] 8 byte 408
32 bit Decode Location Top 0 - 15 2 byte
Decode Location Left 0 - 15 2 byte
32 bit Decode Location Height 0 - 15 2 byte
Decode Location Width 0 - 15 2 byte
Appendices
A - 24
V430-F Series Autofocus Multicode Reader User Manual for Communication Settings
