Member Name Data Type Bit Number Data Length Byte Offset
32 bit Code Type DINT 4 Byte 416
Aztec Code 0 1 bit
Micro QR Code 1 1 bit
Postal Code 2 1 bit
Code 39 3 1 bit
Codabar 4 1 bit
Interleaved 2 of 5 5 1 bit
UPC EAN 6 1 bit
Code 128 EAN 128 7 1 bit
Code 93 8 1 bit
PDF417 9 1 bit
Pharma Code 10 1 bit
DataMatrix 11 1 bit
QR Code 12 1 bit
BC412 13 1 bit
RSS14 14 1 bit
RSS14 LTD 15 1 bit
RSS14 EXP 16 1 bit
Micro PDF 17 1 bit
Composite 18 1 bit
Dot Code 19 1 bit
Reserved 20 - 31 12 bit
32 bit Pixels per Element REAL 0 - 31 4 byte 328
32 bit Decode 4 Length DINT 0 - 31 4 byte 424
Decode 4 Data SINT[72] 0 - 575 72 byte 428
N Decode Input Assembly (Instance ID: 105)
N Decode Input Assembly supports any number of multiple symbol readings. Use this when you want
to execute arbitrary number of multiple symbol readings and query symbol information such as symbol
position coordinates for each symbol. Since the data structure of the Read result is a variable length
up to a maximum of 456 bytes, the user needs to access the data such as the read character string by
referencing the data offset value.
N Decode Input Assembly Member Structure
Member Name Size (Bytes)
INFO BITS 1
RESERVED 1
CONFIGURATION CHANGE DETECTION 1
RESERVED 1
DEVICE STATUS 4
FAULT CODE 4
COUNTERS 24
READ CYCLE REPORT STATIC MEMBERS 8
RAW INPUT DATA 456
Total Size: 500 Bytes
Appendices
A - 25
V430-F Series Autofocus Multicode Reader User Manual for Communication Settings
A-2 EtherNet/IP Detailed Specifications
A
A-2-1 Assembly Memory Allocation
