Member Description
• INFO BITS
MXL/SLC Input Assembly (Instance ID: 102) on page A - 8 - Same structure
• Configuration Change Detection
MXL/SLC Input Assembly (Instance ID: 102) on page A - 8 - Same structure
• Device Status
MXL/SLC Input Assembly (Instance ID: 102) on page A - 8 - Same structure
• Error Code
MXL/SLC Input Assembly (Instance ID: 102) on page A - 8 - Same structure
• Counters
MXL/SLC Input Assembly (Instance ID: 102) on page A - 8 - Same structure
• Read Cycle Report
Read Cycle Report Size (Bytes)
Capture Time 2
Total Decode Time 2
Total Read Cycle Time 2
Number of Decodes in Read 1
Number of Decodes in Read 1
・Capture Time
The time required for image capture. (milliseconds)
・Total Decode Time
The time required for decoding a symbol. (milliseconds)
・Total Read Cycle Time
The total time taken to read symbols. This encompasses the total time of image capture, decoding
and overhead. (milliseconds)
・Number of Decodes in Read Cycle
The total number of detected symbols in the Read Cycle.
・Number of Decode Reports
The total number of Decode information data related to detected symbols.
Equal to the total number of detected symbols in the Read Cycle.
• Raw Input Data
Variable length Read data is stored.
Read Data Structure Size (Bytes) Offset
Offset of Report 1 4
Offset of Report 2 4
… ...
Offset of Report N 4
Decode Cycle Report 1 16 Offset 1
Decode Length 1 4
Decode Data 1 Variable length
Decode Cycle Report 2 16 Offset 2
Decode Length 2 4
Decode Data 2 Variable length
… ...
Appendices
A - 26
V430-F Series Autofocus Multicode Reader User Manual for Communication Settings
