Read Data Structure Size (Bytes) Offset
Decode Cycle Report N
*1
16 Offset N
Decode Length N
*1
4
Decode Data N
*1
Variable length
*1. N is the value output for Number of Decodes in Read Cycle.
・Offset of Report (n)
This is the offset value from the Start Address for Raw Input Data to the address where the nth
Read result is stored.
・Decode Cycle Report (n)
Information of the nth Symbol. MXL/SLC Input Assembly (Instance ID: 102) on page A - 8 - Same
structure
・Decode Length (n)
Stores the number of characters that comprise the nth symbol.
・Decode 4 Data (n)
Stores the Read string of the nth symbol.
Assembly Memory Allocation
Member Name Data Type Bit Number Data Length Byte Offset
32 bit InfoBits SINT 1 Byte 0
Bit Run Mode 0 1 bit
Bit Connection Faulted 1 1 bit
Reserved 2 1 bit
Reserved 3 - 7 5 bit
Reserved SINT 1 Byte 1
Configuration Change
Detection
SINT 1 Byte 2
Config Change Detect 0 1 bit
Reserved 1 - 7 7 bit
Reserved ‐ 1 byte 3
Appendices
A - 27
V430-F Series Autofocus Multicode Reader User Manual for Communication Settings
A-2 EtherNet/IP Detailed Specifications
A
A-2-1 Assembly Memory Allocation
