Omron V430-F Series User Manual For Communication Settings

Tag Set Settings
Setting Item Setting
Input
Tag Set Name Tag Set Name on PLC
Size Input Assembly Dependency
• 84, 176, 248, 500 byte
Output
Tag Set Name Tag Set Name on PLC
Size Output Assembly Dependency
• 4 and 12 byte
Connection Settings
Setting Item Setting
Input
Target Variable Input Assembly Dependency
• 100, 101, 102, 103, 104, 105
Size Input Assembly Dependency
• 84, 176, 248, 500 byte
Originator Variable Variable defined on the PLC
Size Input Assembly Dependency
• 4 and 12 byte
Connection type Point to Point connection
RPI 1.0 to 65.0ms (Default: 5.0ms)
Timeout RPI × (4 to 512) (Default: RPI × 512)
Output
Target Variable Output Assembly Dependency
• 197, 198
Size Output Assembly Dependency
• 4 and 12 byte
Originator Variable Variable defined on the PLC
Size Output Assembly Dependency
• 4 and 12 byte
Connection type Point to Point connection
3 Controlling Operation and Data Output with Ethernet
3 - 9
V430-F Series Autofocus Multicode Reader User Manual for Communication Settings
3-1 Controlling Operation and Data Output with Ether-
Net/IP
3
3-1-5 Tag Data Link Setting Methods
