Precautions for Correct Use
• If I/O memory addresses are specified for the communications areas, the information in the
communications areas will be cleared when the operating mode of the PLC changes unless
addresses in the CIO Area, which holds memory, are specified.
• The following Assembly objects are required to specify instances when the EDS file is not
used.
Setting the Assembly Object
Setting item Setting Value Note
Instance ID 100 Small Input Assembly
101 Big Input Assembly
102 MXL/SLC Assembly
103 1 Decode Input Assembly
104 4 Decode Input Assembly
105 N Decode Input Assembly
197 Output Assembly
198 Output Assembly (Legacy)
