Section 6 Operation Interface
Network Settings View
If you change the network settings, restart the Reader/Writer. The new settings will be effective after a restart of the
Reader/Writer.
When you restart the Reader/Writer after you change the IP address, WEB browser can not reconnect to the Reader/
Writer. If you re-specified the new IP address in the address field of the browser, the screen will be appeared.
The error message is displayed if you change the configuration during the Reader/Writer is executing RF tag
communication or Noise measurement.
Item name Description Setting range Default
IP address IP address --- 192.168.1.200
Subnet mask Subnet mask address --- 255.255.255.0
Gateway address Gateway address --- 192.168.1.254
BOOTP Options Fixed setting, Obtain from BOOTP
server, or Fix at the IP address
which is obtained from BOOTP
server
--- Fixed setting
Web Port The port number used for browser
communications
1024 to 65535 7090
Web password 15 ASCII characters max. 15 ASCII characters max. None
Device name 63 ASCII characters max. 63 ASCII characters max. None
Click this button to set
the displayed values.
Click this button to set
the displayed values.
