Omron V680S Series User Manual

Section 8 RF Tag Installation Precautions
V680-D8KF67M
 Influence of Surrounding Metal
The V680-D8KF67M can be surface-mounted or it can be embedded in metal. However, do not allow
the height of the metal to exceed the height of the V680-D8KF67M.
 Mutual Interference of RF Tags
If you use more than one RF Tag, separate them by at least the interval shown below to prevent
malfunctions due to mutual interference.
If the distance between the RF tags is too short, read / write distance will be reduced.
 V680S-HMD64-EIP Reader/Writer
 V680S-HMD66-EIP Reader/Writer
4.5mm max.
Metallic material
Embedded
Metallic material
Surface-mounted
RF TagRF Tag
Metallic material
RF Tag
xx
0
10
20
30
40
50
60
70
80
90
100
10 20 30 40 50 (mm)
(%)
Distance (x) from surrounding metal
0
10
20
30
40
50
60
70
80
90
100
10 20 30 40 50 (mm)
(%)
Distance (x) from surrounding metal
Communications range (range with metal at back surface = 100%)
V680S-HMD64-EIP and V680-D8KF67M
Communications range (range with metal at back surface = 100%)
V680S-HMD66-EIP and V680-D8KF67M
70 mm min.
70 mm min.
90 mm min.
90 mm min.
