Omron V680S Series User Manual

Section 8 RF Tag Installation Precautions
V680S-D8KF67M
 Influence of Surrounding Metal
The V680S-D8KF67M can be surface-mounted or it can be embedded in metal. However, do not allow
the height of the metal to exceed the height of the V680S-D8KF67M.
5 mm max.
Metallic material
Embedded
Metallic material
Surface-mounted
RF TagRF Tag
Distance (x) from surrounding metal
V680S-HMD63-EIP and V680S-D8KF67M
Communications range (range with metal at back surface = 100%)
V680S-HMD66-EIP and V680S-D8KF67M
xx
0
10
20
30
40
50
60
70
80
90
100
10 20 30 40 50 (mm)
(%)
0
10
20
30
40
50
60
70
80
90
100
10 20 30 40 50 (mm)
(%)
0
10
20
30
40
50
60
70
80
90
100
10 20 30 40 50 (mm)
(%)
Metallic material
RF Tag
Distance (x) from surrounding metal
Communications range (range with metal at back surface = 100%)
Distance (x) from surrounding metal
Communications range (range with metal at back surface = 100%)
V680S-HMD64-EIP and V680S-D8KF67M
