7
Controller system settings
7-31
■
DeviceNet address ID
‹
DEVADD
›
This parameter sets the DeviceNet station number. When this parameter is initialized, "0" is set.
■
DeviceNet baudrate
‹
DEVCOM
›
This parameter sets the DeviceNet baud rate. When this parameter is initialized, "0: 125kbps" is set.
Setting Meaning
0 125kbps
1 250kbps
2 500kbps
3 Auto
■
DeviceNet I/O type
‹
DEVTYP
›
This parameter selects the number of channels shared by the DeviceNet applicable unit from "Normal" or "Compact".
When "Normal" is selected, each of the input and output shares 24CH (I/O including word data).
When "Compact" is selected, each of the input and output shares 2CH (dedicated/ general-purpose I/O).
When this parameter is initialized, "0: DEV_NORMAL" is set.
Setting Meaning
0 DEV_NORMAL
1 DEV_COMPACT
■
EtherNet/IP IP address
‹
EIPADD
›
This parameter sets the IP address. When this parameter is initialized, "0.0.0.0" is set.
■
EtherNet/IP subnet mask
‹
EIPSUB
›
This parameter sets the subnet mask. When this parameter is initialized, "0.0.0.0" is set.
■
EtherNet/IP default gateway
‹
EIPDEF
›
This parameter sets the gateway. When this parameter is initialized, "0.0.0.0" is set.
■
EtherNet/IP DHCP enable
‹
EIPDHCP
›
This parameter sets the DHCP function VALID or INVALID.
Set this parameter to "VALID" when assigning the IP address, etc. from the host unit. When this parameter is initialized,
"0: INVALID" is set.
Setting Meaning
0 INVALID
1 VALID
* When the DHCP function is valid, the setting value of IP address, subnet mask and gateway is "0.0.0.0".
