3. Check and Preparation
3-7
3.5 Setting the Measurement Conditions
Set the measurement conditions for the object to measure. The measurement conditions
include six items: the number of channels to use (USECH), the measurement target circuit
(TYPE), the dedicated CT type (CT), the voltage of the measurement target (VOLT), power
factor (PF) and frequency (FREQ).
Note
Refer to the sections below for details on messages displayed on the display unit and
operational key functions.
Refer to: 2.1 Display Unit, 2.2 Control Unit, and 4.2 Setting (FUN Mode Operation)
(1) Switching to "FUN" Mode
"FUN" mode should be entered for setting measurement conditions. Press the MODE key
until the "FUN" indicator at the right of the display starts blinking.
(2) Setting the Number of Channels to Use (USECH) (Example: 2 Channels)
CLEAR
("FUN" Blinking)
▽
△
key until "USECH" appears at the upper row on
the display.
▽
△
USECH
2CH
Check if "2CH" is displayed at the lower row. If it is displayed, the
number of channels has been already set to "2", and no other
setting is required.
If the above is not displayed, press the SET/REC/STOP key.
The lower row indication starts blinking.
SET/REC/STOP Key
1CH
↑
Press the ▽or △ key to display "2CH" at the lower row.
▽
△
2CH
↑
Press the SET/REC/STOP key to apply "2CH" for the number of
channels to use. The blinking at the lower row stops.
SET/REC/STOP Key
USECH
2CH
Next, proceed to the measurement target circuit type (TYPE) and
dedicated CT type (CT) settings.
RUN Mode
FUN Mode
"FUN" Blinking
THR Mode
Twice
MODE Key
MODE Key
To Next Page
