4. Setting the Unit (Unit Operation)
4-1
4. Setting the Unit (Unit Operation)
4.1 Setting Procedure and Operation Modes
The following diagram shows the Portable Power Monitor setting procedure flow:
The Portable Power Monitor provides the three operation modes, which can be switched
with the MODE key.
To change the mode from RUN to FUN, press the MODE key twice. At the first press of the
MODE key, “RUN” blinks and at the second, "FUN” blinks and the mode is entered.
Use the △ and ▽ keys to switch among setting and display items in each operation
mode.
Table: Operation Mode
Display
Name
Description
"RUN" ON
Measurement
Execution Mode
(RUN Mode)
Used for power measurement and recording.
"FUN" Blinking
Function Setting
Mode
(FUN Mode)
Entered to make measurement and recording
settings.
"THR" Blinking
Threshold Setting
Mode
(THR Mode)
Entered to make setting on the upper threshold
value for power alarm output.
Note
The mode cannot be changed during data recording in the internal memory in RUN mode
("REC" indicator is ON).
RUN Mode
FUN Mode
THR Mode
MODE Key
Twice
MODE Key
MODE Key
△/▽ Key △/▽ Key △/▽ Key
RUN Mode
Operation
FUN Mode
Operation
THR Mode
Operation
