26
GENERAL SETUP CHAPTER 2.
Access: Shortcuts panel > Settings
2.1 COLLECT
Possibility to protect* the modification of some route data: sensor position pictogram, location or point picture,
barcode, rotation speed for measurement done by tachometer
Possibility to protect* the functions ‘Delete’ and ‘Reset’ for routes not downloaded.
Selection of data type displayed during acquisition: progress bar only, overall level, spectrum or time wave
* The protection is applied if you define a password on the last line of > Settings > About (See § 2.8)
2.2 MEASUREMENT
Acquisition power supply permanent or not: If this option is set to YES, the acquisition components are
permanently supplied. If it is set to NO, its supply is activated only when a measurement is to be carried out,
but it requires a short waiting time before signal stabilisation. The advantage of permanent supply is the speed
to carry out numerous measurements. But the current consumption will be a little higher, and so the instrument
autonomy will be shorter.
IEPE stabilisation time: increase pre-measurement delay for IEPE transducers with large stabilisation time.
Unit = second.
WARNING: when IEPE input type is selected, a constant current is powered up (current source: 4 mA – 23 DC).
It is important to check that the signal source is compatible.
Pyrometer:
o External: temperature is measured on DC input
o Internal: temperature is measured with built-in pyrometer
Pyrometer unit : °C / °F
Measurement channel number:
o Single: measurement is always done on channel 1 (connector A) for wired sensor or on Z axis for WLS
sensor
o Multi: measurements are done on channels 2 to 4 for triaxial compatible accelerometer configuration
(connector B) and on channels1 to 4 otherwise (connectors A and B)
Note: if the instrument is equipped with 1 wired channel option, the mode “Multi” is not effective when
“Accelerometer link” is set to “Wire”
Accelerometer link:
o Wire: accelerometer is connected to connector A or B
o Wireless: use the WLS sensor (see § 1.11.2).
Note: Accelerometer link setting is not used for measurement synchronous with the tachometer input (e.g.,
Balancing module)
