APPENDIX CHAPTER 6.
6.1 APPENDIX 1: DATA STORAGE ORGANIZATION
When the instrument is connected to the PC (see § 1.12), you can see the contents of its memory. The
organization is as follows:
 ‘Balancing’: Data base including all the balancing tests
 ‘balancing_report_templates’: copy to this folder the customized balancing report templates
 ‘Collect’: there is one database for each route. It is stored in a tree structure ‘PC_server/Data_base/Route’
 ‘Export’:
o Measured route files (.zdl files) exported from the Collect module. This type of file can be
downloaded in the PC database with NEST Collect module.
o Reports (.docx files) generated from the Balancing module.
o Log files
 ‘Import’: copy to this folder the route files (.zld files) to be imported from the Collect module. This type of file
can be generated by NEST Collect module.
 ‘screenshots’: includes all the screenshots generated with the shortcut .
