 File name is: Route-name_Database-name_Computer-name.zld
o Copy the file:
 On a folder “Import” of a USB memory stick
or
 Directly in the folder “Import” of the instrument memory (see § 6.1)
 On FALCON:
o Go to “Collect” module
o If you are using a USB memory stick, insert it in the port G behind the trapdoor
o Click on Import
o Select the route to import.
3.4 ROUTE LIST SCREEN
This screen lists all the routes loaded in the instrument. The first one “OFF_ROUTE” is specific and always there. It
is used to take make measurement on machines not loaded from the PC. For more details, see § 3.7
The other routes are listed below. On the top of the screen you can select how to sort the routes as follows:
 Name
 Number of points
 Completed percentage
 Measurement date
 Loading date
 Downloading date
Functions of the screen:
OK: go to the selected route
Note: the Auto-controller version cannot open a route with more than one machine.
Properties: display the properties of the selected route:
 Name
 Source database: name of the computer and of the database
 Loading date
 Measurement date
 Downloading date
 Number of machines
 Number of measured points
 Completion in %
 Total number of points
 Used memory
Import: import a route from a USB memory stick or the internal memory. See § 3.3.2.
Export: export a route to a USB memory stick or the internal memory. See § 3.6.2.
Reset: erase all measurements of the selected route. It is possible to protect this function for the routes
which have not been downloaded (see § 2.1).
Delete: delete the selected route. It is possible to protect this function for the routes which have not been
downloaded (see § 2.1).
Exit: return to the Home screen.
