OneProd FALCON - 2.4 Display and System Settings

29
Brand of ACOEM
2.6 CAMERA
Set the access to the barcode reader and the camera. The access to the camera can be protected by password
(The protection is applied if you define a password on the last line of Settings > About).
2.7 TOUCHSCREEN
 Screen brightness setting
 Screen calibration : it may necessary to adjust the calibration. Click accurately in front of each cross
appearing on the screen with a soft and thin tip, then click once more on the screen. To store the new setting,
exit using function “Save” .
Note: if the calibration state does not allow using the touchscreen, it is possible to connect a mouse on port G and
use it to reach the calibration screen. Use then the touchscreen to calibrate it.
2.8 ABOUT
Display of:
 Product version: Main firmware, DSP, Hardware
 Instrument serial number
 Network addresses
 License information:
o Number of channels: 1, 2 or 4 (for wired sensors only, WLS sensor is always triaxial)
o Camera: Yes or No
o Wi-Fi: Yes or No
o Collector: Yes or No
o Auto-controller: Yes or No
o Premium: Yes or No
o Diagnosis: Yes or No
o Balancer: Yes or No
o Frequency response: Yes or No (future version)
o Run-up/Coast-down: Yes or No (future version)
o Monitor: Yes or No (future version)
o Off-route: Basic or Expert
o Long-time wave: Yes or No
o Defect factor: Standard or ED (specific)
o Validity date: the date or unlimited
Input of:
 License number to upgrade the instrument
 Password to protect the access to some settings:
o In Collect: see § 2.1
o In Camera: see § 2.6
o In Network: see § 2.10
