3.5.5 Inspection information
Functions of the screen using the shortcuts:
It is possible to add inspection information using functions accessible through the shortcuts panel:
Inspection picture: see also § 1.14.1.
The pictures are downloaded as attached to the measurement date of the machine and visible in the NEST
Expertise REPORT or in XPR “Measurement information” window, “Appendix” tab.
Inspection note: see also § 1.14.2.
The text inspection note is downloaded as attached the measurement date of the machine and visible in XPR
“Measurement information” window, “Advice” tab.
Inspection vocal note: see § 1.14.4.
The vocal inspection note is downloaded as attached the measurement date of the machine and visible in XPR
“Operation” mode, “Archive” tab.
3.5.6 Specific measurements (Pyrometer, Stroboscope)
Temperature measurement using the pyrometer
For the pyrometer please read the safety instructions delivered with the instrument (printed and on the
CDROM)
In Measurement setting (see § 2.2), if “Pyrometer” = “Internal”, temperature measurement of the route with input
type = DC is done with the built-in pyrometer.
A warning is displayed before switching on the laser beam. Make sure that nobody stands in its direction.
Aim the beam at the target (Warning: due to the distance between the pyrometer cell and the laser source
the beam is decentred by 3 cm on the right hand side of the target).
Press to start acquisition
See also § 1.14.7.
Rotation speed using built-in stroboscope
For the stroboscope please see the safety instructions delivered with the instrument (printed and on the
CDROM)
If the machine is configured as “Variable speed”, it possible to measure the rotation speed using the built-in
stroboscope.
For more details, see § 1.14.8.
