6.2 APPENDIX 2: SPECIFICATIONS
For the main specification see FALCON technical datasheet ref TDS3143
6.2.1 Spectrum measurements
The following tables indicate the maximum overlapping available according to:
 Number of simultaneous channels
 Analysis frequency
 Number of frequency line
Max Overlapping
in % for 1 channel
Number of FFT lines
100K
50K
25K
12800
6400
3200
1600
800
400
Analysis
frequency
80 kHz
50
75
75
75
75
75
75
75
75
40 kHz
75
75
75
75
75
75
75
75
75
20 kHz
75
75
75
75
75
75
75
75
75
10 kHz
75
75
75
75
75
75
75
75
75
Max Overlapping
in % for 2 channels
Number of FFT lines
100K
50K
25K
12800
6400
3200
1600
800
400
Analysis
frequency
80 kHz
0
50
50
50
50
75
75
75
75
40 kHz
50
50
75
75
75
75
75
75
75
20 kHz
75
75
75
75
75
75
75
75
75
10 kHz
75
75
75
75
75
75
75
75
75
Max Overlapping
in % for 3 channels
Number of FFT lines
100K
50K
25K
12800
6400
3200
1600
800
400
Analysis
frequency
80 kHz
0
0
0
50
50
50
50
75
40 kHz
0
50
50
50
75
75
75
75
75
20 kHz
50
75
75
75
75
75
75
75
75
10 kHz
75
75
75
75
75
75
75
75
75
Max Overlapping
in % for 4 channels
Number of FFT lines
100K
50K
25K
12800
6400
3200
1600
800
400
Analysis
frequency
80 kHz
0
0
0
0
50
50
50
75
40 kHz
0
0
50
50
75
75
75
75
75
20 kHz
0
50
75
75
75
75
75
75
75
10 kHz
75
75
75
75
75
75
75
75
75
