6.2.2 Long time-wave measurement (option)

The following tables indicate the maximum number of samples and time wave duration according to:

 Number of simultaneous channels

 Analysis frequency

There are two cases to consider:

 Each point has only 1 time wave in the measurement list (1)

 There is also an overall level measurement in the list (2)

Depending of the configuration, if the time wave is displayed during the acquisition, the limit can be

extended to the one of the previous case.

(1) Only one time wave measurement per channel

Analysis/sampling

frequency

Max number of samples / acquisition time (s)

1 channel

2 channels

3 channels

4 channels

80 / 204.8 kHz

4M / 20 s

2M / 10 s

40 /102.4 kHz

4M / 40 s

2M / 20 s

1M / 10 s

20 / 51.2 kHz

4M / 80 s

2M / 40 s

1M / 20 s

10 / 25.6 kHz

4M / 160 s

2M / 80 s

1M / 40 s

5 / 12.8 kHz

4M / 320 s

2M / 160 s

1M / 80 s

2 / 5.12 kHz

4M / 800 s

2M / 400 s

1M / 200 s

(2) Time wave measurement with an overall level measurement in the list
