3.7.4 Create a new measurement on a group of point in Off-route
From OFF_ROUTE, measurement list screen:
Display additional functions
Add a measurement using a template. The template measurement is selected from OFF_ROUTE route or
any other routes stored in the instrument. The selection is applied on all the points of the group.
Notes:
For Accelerometer, Velocimeter, and Other dynamic input types, it is also possible to select if the sensor is
power supplied (IEPE) or not (AC).
A template route is supplied on the instrument CD (see§ 3.7.6).
The function “Save” creates the new measurement. “Cancel” exits with no creation.
3.7.5 Modify a measurement on a group of points in Off-route
From OFF_ROUTE, measurement list screen:
Display additional functions
Modify: modify the properties of selected measurement
Notes:
If there are several points in the current group with different properties, the modification is done on the
base of the setting of the 1
st
point. In this case a warning is displayed to avoid wrong operations.
If measurement is already done, properties can be displayed but cannot be changed. To make a
modification you must first reset all the measurements of the group with .
The function “Modify” is not accessible for machines with automatic diagnosis.
Properties are displayed on 2 or 3 tabs:
3.7.5.1 Tab 1 Input and measurement type:
Measurement identification: up to 20 characters. If the name already exists, a re-indexed name is proposed
when saving the new measurement.
Input type: select the item corresponding to the used sensor type. The list is:
o Accelerometer IEPE
o Accelerometer AC
o Velocimeter IEPE
o Velocimeter AC
o Displacement AC
Note: if the parameter is Relative displacement or Position (Proximity probe) input range is [-24 to
0V], if the parameter is Absolute displacement input range is [-10 to +10V].
o IEPE (other)
o AC (other)
o DC
o Tacho input
o Keyboard: manual input using keyboard
