CHAPTER 3.
COLLECTOR MODULE
3.1 INTRODUCTION
The Collect module is used to run measurement programs loaded from NEST Predictive Maintenance Software.
These measurement programs are commonly called Routes. Once the measurements are performed, data are
downloaded to the PC for post-processing and storage in the database.
There are 2 levels of functions:
 Advanced
 Premium
There are also 2 possible options:
 Long-time wave to extend the length of acquisition
 Diagnosis: management of machine created with NEST machine setup using the optional mode “Automatic
Diagnosis”.
Advanced
Premium
Overall level
OK
OK
Spectrum *
6400 lines
102400 lines
Envelope
OK
OK
Zoom
No
OK
Vector (phased spectrum)
OK
OK
Time (without long time wave option)
8K samples
64K samples
Long-time wave option *
No
Option
* For detailed limitations:
 Spectrum: see § 6.2.1
 Long-time wave: see § 6.2.2
To start, click on from the Home screen.
For screen organisation, see next chapter.
