3.5.8 Channel organisation
It is possible to use FALCON with WLS sensor or with 1 to 4 wired inputs.
The point to channel association depends on:
 Instrument setting: see § 2.2.
o Wired channel number: Single or Multi
o Accelerometer link: Wire or Wireless (WLS sensor)
 Number of optional channels of the instrument: see § 2.8, License information
 Measurement input type
 Configuration of measurement points: (horizontal or vertical shaft, location and measurement direction)*:
o Compatible with triaxial measurement: for triaxial measurement, the instrument groups together 1 to 3
points of the same machine with:
 the same location
 direction compatible with triaxial measurement, i.e.:
 For horizontal shaft:
o axial, horizontal and vertical measurement direction
Example:
Point
Location
Direction
Pt1-Ax
NDE
Axial (Ax)
Pt1-H
NDE
Horizontal (H)
Pt1-V
NDE
Vertical (V)
or
o axial, radial oblique & and radial oblique 2 measurement direction
Example:
Point
Location
Direction
Pt1-Ax
NDE
Axial (Ax)
Pt1-O1
NDE
Rad oblique (1)
Pt1-O2
NDE
Rad oblique (2)
o For vertical shaft: axial, main radial and perpendicular direction
Example:
Point
Location
Direction
Pt1-Ax
NDE
Axial (Ax)
Pt1-RM
NDE
Rad Main (M)
Pt1-RP
NDE
Rad perpendicular (P)
o Not compatible with triaxial measurement: all other cases or 4 points on the same location.
Example: 4 points on 2 bearings
Point
Location
Direction
Pt1-H
MOTOR
None (-)
Pt1-V
MOTOR
None (-)
Pt2-H
MOTOR
None (-)
Pt2-V
MOTOR
None (-)
* Machine shaft direction, location and measurement direction are automatically created in NEST Machine setup.
For machines created in XPR, it must be done manually and shaft is considered as horizontal.
