The rules are the following:
WLS Sensor (Accelerometer link = Wireless)
o Measurement input type = Accelerometer IEPE or Accelerometer AC
Measurement channel number = Multi
Configuration of the points compatible with tri-axial measurement:
point-channel association is done according to the sensor position pictogram.
Configuration of the points not compatible with tri-axial measurement:
measurement is not possible.
Measurement channel number = Single: all measurements are done on sensor Z axis.
Note: in this case it is not necessary to set a location and direction for each point to use WLS
sensor.
o Measurement input type ≠ Accelerometer IEPE or Accelerometer AC: see “Wired inputs”
Wired inputs (Accelerometer link = Wire)
o Instrument with 4-channel option and set on “Multi”:
Measurement input type = Accelerometer IEPE or Accelerometer AC
Configuration of the points compatible with tri-axial measurement: point-channel
association is done on channels 2 to 3 (connector B) according to the sensor position
pictogram
Configuration of the points not compatible with tri-axial measurement: point-channel
association is done on channels 1 to 4 according the point order in the route.
Measurement input type ≠ Accelerometer IEPE or Accelerometer AC: point-channel
association is done on channels 1 to 4 according the point order in the route.
o Instrument with 2-channel option and set on “Multi”: point-channel association is done on channels 1
and 2 for 2 points with the same location according to the order in the route
o Instrument with 1 channel or set on “Single”: all measurements are done on channel 1 (connector A)
Notes:
if there is no location defined, points are measured one by one on channel 1 (Connector A)
if there is more than 4 points on the same location, points are measured one by one on channel 1
(Connector A)
MVP 2-channel measurement: measurement is done on channel 1 (Connector A) and channel 2
(Connector B) for instrument with 2 or 4-channel option.
Trick: for wired measurement
If you have to select a triaxial sensor position pictogram measurement is done on connector B (Channels 2
to 3)
If not, measurements are from left to right on channels 1 to 4.
