Onicon F-4300 - Series Transducer Dimensions

F
-
4300 CLAMP
-
ON ULTRASONIC FLOW METER
ONICON Incorporated 727.447.6140 Page 17 onicon.com
3.3.1.2 10 Series Transducer Dimensions
SIDE VIEW
END
VIEW
1.61"
1.60"
0.81"
0.94"
0.75"
2.12"
8.50"
1.00"
3.3.1.3 20 Series Transducer Dimensions
SIDE VIEW
1.25"
2.20"
END
VIEW
1.20"
2.10"
A
4.25"


