F
-
4300 CLAMP
-
ON ULTRASONIC FLOW METER
ONICON Incorporated 727.447.6140 Page 41 onicon.com
SECTION 4.0 START
-
UP
pre-programmed into the memory of the meter. This pre-programmed site is based on installation data provided to
ONICON when the meter was ordered. The information programmed into the meter is also provided in a document that
between programmed parameters and actual site conditions, then the programming for the site must be edited before it
contact ONICON.
4.1 NAVIGATING THE RUN MODE & PROGRAMMING PAGES
The diagram on the next page shows the F-4300 menu system. Arrows show the four directions to navigate between
menu boxes. Pressing a corresponding keypad arrow will move to the next item in the direction shown.
Increase or decrease numerals with the and keys.
Programming values are stored permanently after pressing the .
Run Mode View
To Next Page
