4.2 RUN MODE & PROGRAMMING PAGE LAYOUT
--Messages----------
Data Log Logging
Log Used 0.00000%
Sensor Good
--24 hr log----------
 Date Mar. 20/2020
Total 50138 USG
Average 34.82 USG/m
Maximum 52.20 USG/m
Max Time 11:08:00
Minimum 0.000 USG/m
Min Time 9:15:00
--Menu--------------
 Units / Mode
Setup
Calibration
Relay Parameters
Data Logging
Communication
Special Functions
Simulation
Configuration
USG/m
Tot 20130 USG
Relays 1 2 3 4 5 6
0.00
*
* Menu only appears if "New Password" has been
changed from 0000 in "Special Functions" menu.
--Password----------
Password 0000
--Status------------
 Velocity 0.00 ft/s
Flow 0.00 USG/m
Min Flow 4.00 USG/m
Signal Strength 100%
Exp. SOS 4900 ft/s
Meas. SOS 4900 ft/s
--Data Logging-------
 Log Site ID 01
Mode Flow
File Format .LG2
Date Mar. 20/2020
Time 12:28:41
Interval 30sec
Data Log Logging
--Relay Parameters--
 Relay 1
Function Flow
On 1000 USG
Off 0.000 USG
--Simulation--------
 Test Actual
Flow 250USG/m
4-20mA Flow 5.60mA
Relays 1 2 3 4 5 6
--Configuration-----
Serial# 12345
Utility 1.26.0.5
Transit Time 1.38.1
CommBoard 1.18.0
Relays 2
Analog Out 1
--Communication-----
Protocol Modbus
Address 001
BPS 9600
Parity Even
Stop Bits 1
--Special Functions-
 Language English
Analog Out 4-20mA
Backlight High
Reset Totalizer NO
Neg. Totals NO
Rev. Flow OFF
Capture Par NO
Capture WF NO
Restore Defaults NO
New Password 0000
--Setup-------------

Sensor SE16B
Angle 37
Fluid Water
Temp Mode Fixed
Temp 77.0 F
Pipe PVC
OD 4.5000 in
Wall 0.2500 in
Lining None
Crossings 2
Zero Tare No
Sens Space 2.299in
Velocity 0.00 ft/s
Signal
Strength
100 %
--Calibration-------
 Mode Flow
20mA 500.00 USG/m
4mA 0.00 USG/m
LOS Time 10 sec
Min Flow 4.00 USG/m
Damping
Mode FIR
Percent 10%
Window 1.0 ft/s
Cal Constant 1.00
--Units/Mode--------
 Mode Flow
Linear in
Volume USG
Multiplier x1
Decimals 0
Velocity ft/s
Flow USG/m
Decimals 2
Temperature F
