F
-
4300 CLAMP
-
ON ULTRASONIC FLOW METER
ONICON Incorporated 727.447.6140 Page 48 onicon.com
--Setup-------------
Sensor SE16B
Angle 37
Fluid Water
Temp Mode Fixed
Temp 77.0 F
Pipe PVC
OD 4.5000 in
Wall 0.2500 in
Lining None
Crossings 2
Zero Tare No
Sens Space 2.299in
Velocity 0.00 ft/s
Signal
Strength
100 %
4.5 PROGRAMMING MENU PAGES (Continued)
Crossings –
largest signal strength but more diligence is required to mount the transducers
properly.
2 crossings provide the easiest means to mount the transducers, averages
4 crossings provide even more averaging than 2 crosses. 4 crosses will not be
an option unless the transducers overlap in a 2 cross setup, which is dependent
velocity.
Zero Tare –
Sens Space – This function is not editable. This value will automatically calculate
between the inside of both transducers.
Because the meter comes pre-programmed from ONICON, this number is
transducer spacing to the new number provided here.
Velocity – After mounting the transducers and connecting the transducer cable,
Signal Strength – After mounting the transducers and connecting the transducer
cable, you will be able to see the signal strength in real-time. The pipe must be
full of water to get a valid signal strength reading.
