Instruments and controls 105
9 Warning
When the engine is off,
considerably more force is needed
to brake and steer. During an
Autostop the brake servo unit will
still be operational.
Do not remove key until vehicle is
stationary, otherwise the steering
wheel lock could engage
unexpectedly.
Keep engine turned off and let the
vehicle be towed to a workshop.
Low fuel
o illuminates yellow.
Level in fuel tank is too low.
Refuelling 3 256.
Bleeding the diesel fuel system
3 273.
Charging cable connected
j illuminates red.
The vehicle plug of the charging cable
is still connected to the charge port.
The vehicle cannot be started.
Disconnect the vehicle plug from the
charge port and close the charge port
flap.
Charging 3 246.
Vehicle ready
READY illuminates green. The
vehicle is ready to be driven.
Reduced engine power
M illuminates yellow.
The charging level of the high voltage
battery is low. Only reduced engine
power is available.
High voltage battery
temperature high
a illuminates red.
Illuminates briefly when the ignition is
switched on.
Illuminates together with other control
indicators, accompanied by a warning
chime and a corresponding message
in the Driver Information Centre.
Stop engine immediately and
evacuate the vehicle.
Autostop
D illuminates or flashes green.
Illuminates green
Engine is in an Autostop.
Flashes green
Autostop is temporarily unavailable,
or Autostop mode is invoked
automatically.
Stop-start system 3 183.
Exterior light
8 illuminates green.
The exterior lights are on 3 118.
High beam
C illuminates blue.
