40 Seats, restraints
Removing the seats
1. Push the head restraint
downwards and if necessary fold
down the seats of the second row.
Head restraints 3 31
Folding the seats of the second
row 3 37
2. Pull the lever and fold down the
backrest onto the seat cushion.
Pull the handle and tilt the entire
seat forwards (refer to "Folding
the seats" above).
3. Pull the loop to disengage the
locks and remove the seat
assembly from the floor anchor
points.
Installing the seats
1. Attach the seat assembly front
supports to the front anchor
points.
2. Fold the seat backwards to the
floor to fix its rear anchor point.
3. Raise the backrest and adjust the
head restraint.
Longitudinal seat adjustment
Pull the handle, slide the seat, then
release the handle. Try to move the
seat back and forth to ensure that the
seat is locked in place.
