74 Storage
3. Move the partition and lock the
four locking devices on the top
and the bottom.
9 Warning
Take care when operating the
bottom locking devices. Risk of
pinching.
Opening the flap
1. Depending on the positioning of
the partition and the length of the
load fold down the outer rear seat
backrest and / or passenger seat
backrest 3 34, 37
2. Release the locking device of the
flap and open the flap.
3. Secure the flap with the rod.
Closing the flap
1. Fix the rod in the bracket.
2. Close the flap and lock the locking
device.
3. Restore the seats to the upright
position 3 34, 37
Fitting the protective cover
The protective cover must be
installed whenever the side seat
backrest is folded down and the
partition flap is open.
