Vehicle care 279
4. Disengage the retaining lugs to
remove the bulb carrier.
5. Push the bulb slightly down, turn
it and remove it from the bulb
carrier. Replace the bulb:
Tail light / brake light (1)
Turn light / hazard warning flasher
(2) outer bulb
Reversing light (3) inner bulb
Rear fog light (4)
6. Attach the bulb carrier to the light
assembly.
7. Attach the cable to the retainer.
8. Attach the light assembly to the
vehicle body and tighten both
screws.
3rd-brake light
The 3rd-brake light is designed as
LED and can not be changed.
Have lights repaired by a workshop in
case of failure.
Bulb check
Switch on the ignition, operate and
check all lights.
Side turn lights
To replace the bulb, remove the lamp
housing:
1. Slide the lamp housing forward
and remove it at the back.
