Seats, restraints 37
Rear seats
Second row seats
Depending on the equipment, the
rear seat backrest is divided into two
or three parts. All parts can be folded
down.
Before folding rear seat backrests,
execute the following if necessary:
● Move front seats forward.
● Remove the load compartment
cover 3 67.
Folding the seats
1. Push the head restraint
downwards 3 31.
2. Check that the outer seat belts are
lying correctly on the backrests.
3. Pull the release lever on one or
both outer sides and fold down the
backrests onto the seat cushion.
4. Depending on version, fold down
the centre backrest by pulling the
loop.
5. Alternatively fold seat backrests
from the load compartment: pull
lever on left or right sidewall of the
load compartment to fold the rear
seat backrests.
9 Warning
Take care when operating the rear
backrests from the load
compartment. The backrest is
