2.3 Reading the status LEDs
On/Off indicator LED: The illuminated power switch is located in the top-left corner of
TX1 and it displays a white LED when the unit is on.
DC In LED: The TP6 power supply cable has a blue LED ring near the end of the barrel
connector that indicates the TX1 power supply is receiving adequate DC input power.
Activity LED: The multi-color activity LED is located in the lower-right corner of TX1. It is
white when the unit is booting up, blinking white when a power issue is detected, off
when the unit is idle, blue when an operation is in progress, blinking green when an
operation completes successfully, and blinking red when an operation fails.
Network Interface LED: The 10 gigabit Ethernet connector is located on the back of TX1
and it has two LEDs. The table below provides details for interpreting the status of these
network interface LEDs.
(Indicates link status
Green/Yellow LED
2.4 Interpreting audio feedback
TX1 plays one of two sounds that indicate status at the end of a job. A chime sound plays
for a successful job, and a buzzer sound plays for a failed job. You can change the
volume of the sounds or disable them from the System Settings submenu in the side
navigation menu.
2.5 On-screen warnings
TX1 will provide, as necessary, on-screen warnings within various settings and
operations screens of the user interface. Yellow warnings call the user’s attention to a
potential risk, but do not impede operations. Red warnings mean either that a selected
setting cannot be accommodated, an operation has failed, or a potential exists for
forensic evidence to be missed, such as when a DCO or AMA is detected and not
removed. Users are encouraged to pay attention to and read any displayed warnings
when they appear and proceed accordingly.
