10
Recommendation
・
An optional attachment (DA-1) for the DO sensor is also available.
This is to be used when installed in a location with fast water currents.
・
DO sensor attachment includes items (1) to (4) shown in the following
figure.
* The VP-40 polyvinyl pipe to be prepared by the user.
500
(Recommended)
300
(Recommended)
398
505
Ø60.5
675
100100
Pole stanchion (PS-1)
(1) 4-U bolt
SUS304 50A M10
(4) Pipe attachment joint
PVC (1¼-11½ inch NPT male screw/40A)
(3) 2-fitting
(2) 2-pipe hanger (40A)
*To be prepared by the user.
