4-20 mA Setting
15
7
4-20 mA Setting
Set the 4-20 mA signal output setting from SC-U1.
The factory default setting is OFF for 4-20 mA signal output.
To set 4-20 mA output setting, press
.
Select an item to output by 4-20 mA signal.
Select an item from the following.
Output item selection
Output item
[Display]
Dissolved oxygen concentration
[DO]
Temperature
[Temp.]
Dissolved oxygen % saturation
[%Sat.]
Oxygen partial pressure
[O-Press]
For operation, refer to the "Universal Transmitter SC-U1 Operation
Manual", "5.3 4-20 mA Setting" and "
◆
Output Item Select".
Caution
Pressing automatically retains the measurement value.
Caution
When “Display item” P.13 is changed, the output item of the
channel of 4-20 mA setting that have set the display item
becomes OFF. Set again if necessary.
