Optex DOS-20 - Extension of Sensor Cable

11
The standard length of the sensor cable is 10 m. To extend the cable, refer to
the following.
To extend the cable, connection using pull box is recommended.
・
The cable clamp fits the cable sheath diameter of 6 to 8 mm.
・
The sensor cable must be shielded (CVV-S) with a nominal
cross-sectional area of 0.2 to 1.25 mm
2
.
Max. cable length 1200 m
(nominal cross-sectional area of 0.2 to 1.25 mm
2
.)
Pull box, etc.
Extension of sensor cable
