Opticon
OPI 2201
Specifications Manual
14
6.5.2. Output Specifications
Parameter Value
Output voltage 6.0 V ±5%
Maximum current 2.0 A
Power ripple 0.1 Vp-p max. (10-100 kHz)
7. Optical Specifications
The auto-focus function is enabled after aiming the center of the barcode by the laser light. The
aiming operation is activated when pressing the trigger key. The scan engine requires 100ms
to capture the image with auto-focus after triggering. Ambient light might affect the detection of
the scan field and the time that is required for scanning.
7.1. Imager Scanning
Parameter Specification Unit Note
Light-emitting element Red laser diode —
Emission wavelength 650 ±10 (25° C) nm
Light output 1.0 or less mW
InGaIP red LED —
Peak wave length 645 nm
Directivity angle: 2Φ 1/2 (*1) 30°
60°
Light-emitting element
(4 x LEDs)
Maximum radiation output (*2) 12600 lx
5040 mcd
Scanning method SXGA (1.3 million pixels) CMOS
area sensor (gray scale)
— MCLK: 48MHz
Number of effective
pixels
SXGA 1280 (column) x 1024 (row)
Readable pixel count is 1282 dots
(column) ×1026 dots (row)
Thermal protection
Frame rate Up to 30 fps
Scan angle Horizontal: 40
Vertical: 32
°
*1: The radiation pattern features: 2pcs in 2 types of LED (which have different directivity
angles).
*2: The figure is measured at 25ºC, IF = 50mA. Class 1M compliant output.
