Opticon

OPI 2201

Specifications Manual

31

10.1.2. Pin Assignment

a) DB9 Pin Assignment

Pin Signal Remarks

1 Shield

2 TxD

3 RxD

4 NC Open (not connected)

5 GND

6 NC Open (not connected)

7 CTS

8 RTS

9 NC Open (not connected)
