10. Cable and Connector
10.1. RS-232C Cable
(Standard specification)
Type: Straight
Diameter: Φ4.8 ±0.5 mm
Length: 1500 ±50 mm
Weight: Approximately 90 g
Figure 18: RS-232C cable
10.1.1. Connectors
a) DB9 connector
Figure 19: DB 9 connector
Connector used: D-sub 9-pin, female
Power supply: EIAJ RC5320A (voltage class2) jack
