Opticon
OPI 2201
Specifications Manual
45
14.3.2. Drop Test (with individual packaging)
No malfunction occurred after the following drop test.
Drop Test: Drop an individually packaged scanner from a height of 150 cm onto a
concrete floor once on its 1 corner, 3 edges, and 6 sides (10 total drop tests).
14.4. Vibration Strength
No malfunction occurred after the following vibration test.
Vibration test: Increase the frequency of the vibration from 12 Hz to 100 Hz with
accelerated velocity 19.6 m/s
2
(2 G) for 60 minutes in non-operating state. Repeat this
routine in each X, Y, Z direction once for 60 minutes each (180 minutes total).
14.5. Dust and Drip Proof
IEC IP42 equivalent
Dust Prevention
Water Prevention
Level Details
2
Vertically dripping water shall have no harmful effect when the enclosure is tilted at an angle up
to 15° from its normal position.
14.6. Cable Strength
No malfunction occurred after the following cable strength test.
Affix the scanner to an immovable object, then pull it using a force of 2.5 kgf (static
loading) for 1 second. Carry out this test 20 times.
14.7. Cable Bending Test
No malfunction occurred after the following cable bending test.
Add a load of 4.9 N (500 gf) to a cable, then bend it at an angle of 90° to both right and
left. Repeat this bending test for 1 million times on the tail of the cable.
Level Details
4 Protected against solid objects greater than 1.0mm
