14. Durability
14.1. Electrical Noise
No malfunction occurred when sinusoidal electrical noise (50 Hz–100 kHz, < 0.1 Vp-p)
was added to the power supply line.
Withstand voltage: AC 1500 V/ per 60 seconds, 10mA or less
Insulation resistance: DC 500 V, 2 MΩ or higher
Current leakage: 250 μA or less / AC 250 V 60 Hz
Power line noise immunity: ± 1kV or lower
14.2. Static Electricity
Air discharge: ±8 kV max. (No malfunction)
±15 kV max. (No destruction)
Contact discharge: ±6 kV max. (No malfunction)
±15 kV max. (No destruction)
Measurement
environment:
Use electrostatic testing device compliant with IEC 61000-4-2
Discharge resistance: 330 Ω
Capacitor charging: 150 pF
14.3. Shock
14.3.1. Drop Test (without packaging)
No malfunction occurred after the following drop test.
Drop Test: Drop the scanner for 5 cycles from a height of 150 cm onto a concrete
floor. (One cycle = five sides—left, right, front, back, and top.)
Figure 30: Drop test
