Opticon OPI 2201 - USB Cable

Opticon
OPI 2201
Specifications Manual
32
10.2. USB Cable
(Standard specification)
Type: Straight
Diameter: Φ4.8 ±0.5 mm
Length: 1500 ±50 mm
Weight: Approximately 70 g
Figure 20: USB cable
10.2.1. Connector
a) USB "A" Connector
Figure 21: USB "A" connector
10.2.2. Pin Assignment
Pin Signal
1 VCC
2 -DATA
3 +DATA
4 GND
